CARBO-FLEX® (FLPN) Cloth
CARBO-FLEX® (FLPN) is heat-resistant, flexible composite fabric that is an aramid, fiberglass and non woven blend of aramid and partially carbonized acrylic fibers. They are the perfect heat resistant fabric to protect personnel in mid-range temperature applications.
Download SDS- Product Specs
- Product Line Information
- Data Sheets
Product Type | Product Number | Series | Weight (oz. per sq. yd) | Count (Warp x Fill) | Unit of Measure | Fabric Type | Cont. Op. Temp. | Available Widths (inches) | Thickness (inches) | 3rd Party Spec. | Data Sheets |
---|---|---|---|---|---|---|---|---|---|---|---|
FLPN1500 15.0 oz | FLPN1500 | FLPN | 15 | 20 x 11 | YD | CARBO-FLEX (Carbon/Aramid Fiberglass) | 500°F (260°C) | 40 | 0.10 | NFPA1971 | Data Sheet |
Show All
Superior protection for people, plants and equipment.
CARBO-FLEX® is composite of aramid-fiberglass and partially carbonized non-woven acrylic for enhanced thermal performance.
An innovative composite developed by AMI, it combines the strength and heat resistance of our aramid and glass fabrics with the excellent DIRECT heat resistance of preox (partially carbonized acrylic).
Fabrics can be carbonized on either or both sides. The result is a fabric that exhibits excellent anisotropic capabilities — meaning that direct heat travels across the carbonized side of the fabric, not through it.
And it delivers the performance without adding weight or stiffness. The result is substantially better heat protection for people, plants and equipment.
Products
Product Number | Data Sheets |
---|---|
FLPN1500 | Data Sheet |
