AMI-TUF® (TGL) Cloth

AMI-TUF® (TGL) is a PTFE-coated fiberglass cloth that can withstand continuous temperatures to 550°F (288°C).  This PTFE coated/impregnated fiberglass cloth has been specifically designed as an exterior insulation jacketing for the fabrication of removable insulation pads that use sewn seam construction. The formulated PTFE compound provides improved water, oil, chemical and abrasion resistance over uncoated fabrics.

We do not stock samples of this product at this time.

Download SDS
  • Made in the USA
  • Product Specs
  • Product Line Information
  • Data Sheets
Product TypeProduct NumberSeriesStandard Put-upUnit of MeasureFabric TypeCont. Op. Temp.Available Widths (inches)Base Fabric Weight (oz. per sq. yd.)3rd Party Spec.Thickness (inches)Weight (oz. per sq. yd)Data Sheets
Cloth 14 ozTGL140

TGL

50 YD/RL

YD

AMI-TUF (Silicone coated)

550°F (288°C)

60

13

ASTM C1695-09

.012

Data Sheet
Cloth 17 ozTGL165

TGL

50 YD/RL

YD

AMI-TUF (Silicone coated)

550°F (288°C)

60

17, 18, 14

ASTM C1695-09

0.017

17

Data Sheet
Cloth 18 ozTGL180

TGL

50 YD/RL

YD

AMI-TUF (Silicone coated)

550°F (288°C)

60

17, 18, 14

ASTM C1695-09

0.018

18

Data Sheet

AMI-TUFTough coated fiberglass stands up to industrial punishment.

AMI-TUF® coated fiberglass cloth is the ideal solution for the outer layer of removable insulation pads on pipes, valves and joints (see AMI-FAB® System for details). Use AMI-TUF tape as pipe wrap in harsh industrial environments. AMI-TUF can also be fabricated into light, medium or heavy duty AMI-GUARD welding blankets; the silicone rubber coating provides a non-slip surface when used as a floor covering in high traffic areas.

  • Silicone rubber coated fabrics provide superior water, oil and heat resistance
  • PTFE (Teflon®) coated cloth provides effective chemical resistance
  • Continuous protection to 500°F (limit of Silicone), 550°F (limit of PTFE)
  • High abrasion resistance
  • Strong and durable
  • Available in 10 colors to match equipment, simplify identification (hot pipes, cold pipes, etc.), or blend with any industrial environment
  • Packaging Guidelines for SGL Materials
(Photo courtesy of PetroHab, LLC. AMI’s FM Approved AMI-TUF® silicone rubber coated fiberglass cloth is the product of choice for these Hot Work Safety Enclosures —sometimes referred to as pressurized welding habitats — used for hot work in refineries, petrochemical plants and other heavy industrial facilities.

(Photo courtesy of PetroHab, LLC.)
AMI’s FM Approved AMI-TUF® silicone rubber coated fiberglass cloth is the product of choice for these Hot Work Safety Enclosures —sometimes referred to as pressurized welding habitats — used for hot work in refineries, petrochemical plants and other heavy industrial facilities.

Products















Product NumberData Sheets
TGL140Data Sheet
TGL165Data Sheet
TGL180Data Sheet
